FOR A VIDEO OF THIS MACHINE: https://youtu.be/3_JvdUbQ6zc
CATALOG SPECIFICATIONS:
CAPACITY:
220 TONS
STROKE:
10"
STRAIGHTENING STROKE, CONTROLLABLE & ADJUSTABLE:
7/8"
DAYLIGHT:
33"
DEPTH OF THROAT:
13-3/4"
RAM SPEED, DOWNWARDS:
60 IPM
RAM SPEED, UPWARDS:
215 IPM
BASE TABLE DIMENSIONS:
13-3/4" x 55"
OVERALL DIMENSIONS:
55" R-L x 81" F-B x 115" HIGH
APPROX. WEIGHT:
16,000 LBS.
EQUIPPED WITH:
LEVER CONTROLLED RAM WITH STROKE ADJUSTMENT
RAM ANVIL
10-5/8" x 59-7/8" MAIN TABLE
13-3/4" x 55" BASE TABLE
25 HP HYDRAULIC MOTOR
